In some industry sectors (for example, diary/meat, and pharmaceutical, chemical, steel, or paper industry sectors), the composition or attributes of products vary to some degree. Therefore, you cannot use a fixed conversion factor to convert quantities of these products into various units of measure. Instead, each batch has to be given an individual conversion factor.
The weights can vary from piece to piece, either due to biological variations or because of weight loss during storage. This variability should not be lost by using fixed conversion factors, because this would mean that many business processes would be based on incorrect values.
In SAP such a process can be mapped in two ways
· Batch-Specific Units of Measure
· Catch Weight Management – IS-CWM Functionality
This document will give you some light on these SAP functionalities.
1. Catch Weight with batch-specific Units of Measure
Create ‘No Dimensions’ Unit of Measurement.
GO>SPRO>SAP NETWEAVER>GENERAL SETTINGS>CLICK ON CHECK UNIT OF MEASURE
Create two dimensions units LBI and CS/LB. LBI will represent as ‘Batch Specific Unit of measurement’ which will be assigned to its original unit of measurement i.e. LB (Pounds). CS/LB is a no dimension unit that will be used to define fractions between cases (CS) and Pounds (LB).
Click on Unit of measurement to create units LBI and CS/LB. Please refer to the screen below.
Maintain the details of LBI and CS/LB as per the above screen.
Maintain the details of LBI and CS/LB as per the above screen.
Activate Batch Specific Unit of Measurement
The batch-specific material unit of measure is an alternative unit of measure of a material, for which base unit of measure can be defined on a batch-specific basis.
While the conversion ratio for other alternative units is predefined in the material, for batch-specific material units of measure, we define:
- The planned conversion in the material
- The actual conversion ratio to the base unit of measure for the batch.
GO TO>SPRO>LOGISTIC GENERAL>BATCH MANAGEMENT>FOLLOWS AS BELOW THE SCREEN
Batch-specific material units of measure are used when the conversion ratio for the unit of measure to the base unit may vary for different batches of a material.
In this case, Base unit of measure is CS (Case) and valuation unit is LBI (Pounds). Planned conversion ratio between these units is defined in the material master, but actual conversion ratio varies batch to batch which may depend on the environmental factors.
To control these situations in SAP, we need to activate ‘Batch-Specific material units of measure’.
We need to activate batch-specific UOM as per the above screen.
Define Batch Specific Unit of measurement
CLICK ON THE SAME ABOVE NAVIGATION PATH.
Create a ‘Batch specific UOM’.
We need to execute the process step as mentioned above.
Click on New Entries in the screen above to define batch specific UOM.
Define the Batch Specific UOM and link it with the actual UOM. Here LBI is batch-specific UOM which is linked to the actual weight unit (dimension ‘Mass’) LB.
Define Calculation of Proportion quantity from Base Quantity
Define the ratio of the proportioning unit to the base unit. This ratio is needed to convert base units to proportion units of measure.
Click on New Entries in the screen above to define the calculation of proportion/product quantity from base quantity.
As per the screen above, we have linked batch-specific UOM with the base unit of measurement.
Define Calculation of Base Quantity from Proportion quantity
Define the quantity calculation with reference to the base unit of measurement.
Here we have defined CS and LBI calculation for no dimension unit CS/LB.
Define attributes of system messages
We need to maintain message XU-033 as an information message. In standard SAP, this message would be set to the error message. Please remove the message category ‘E’ and set it as blank.
In standard SAP, the fraction between two units of measurement is set to two decimal points. If fraction value is defined for three or more decimal values, then the system will issue this as an error message XU-033.
In our case, we need are considering fraction values to five decimal points, so that we can get more accurate values after conversion. Take the following case:-
Number of Cases
Catch Weight (LB)
Ration (CS/LB) = 0.26 when only two decimal allowed
Ration (CS/LB) = 0.25641 when five decimal allowed
From the calculation above, it’s clear that we would get more accurate results when we go for higher decimal points.
So as per the screen below, we have changed the error message category to blank.
Master Data Requirement:
Create following master data for catch weight management,
Create Characteristics CT04
Create three characteristics. One characteristic will store the actual fraction between a number of cases and the actual catchweight. So we have characteristics ‘CATCHFRACTION’, ‘CATCHWEIGHT’ and ‘NUMCASES’ to create. We need to call the CT04 transaction code to create these characteristics in SAP.
Below mentioned screenshots will tell about the properties of these characteristics.
The above screen tells about the ‘CATCHFRACTION’ property.
The above screen tells about the ‘CATCHWEIGHT’ property.
The above screen tells about the ‘NUMCASES’ property.
Dependency will be used to calculate the fraction between the number of cases and the actual catchweight. Call SAP transaction CU01 to create dependency.
Create Class CL01
Create a class for catch weight material. We need to assign all characteristics as mentioned above important thing to note is that ‘organization area’ in the class must be equal to ‘S’. Call CL01 to create a class and assign the characteristics.
Assign Characteristics to Batch Class
Assign characteristics to class CL01
See the screen above for characteristics assignments. We must put ‘Organizational Area’ equal to ‘S’ against the characteristics which will be used for CS/LB conversion.
Maintain Material Master MM02
Assign the catchweight class to the material master classification view and update other parameters in the material master. Please see the screen below to know about various important data in the material master.
Select the additional data information in the material master and click on the ‘proportion/prod unit’ tab to maintain planned conversion factor.
Maintain the planned conversion value into ‘plan value’ as per the screen below.
The valuation category of material must be equal to ‘X’.
Create vendor Info record
Maintain the vendor info record for batch specific UOM.
Price are maintained at batch specific UOM.
Receiving actual CW at the time of MIGO
Create Purchase Order
Use ME21N transaction to create Purchase Order. Here we are using material 69 for which Batch specific UOM is active.
Perform goods receipt (MIGO)
We need to enter actual CW and GR quantity in the classification view as,
Display Stock (MMBE)
Here we can see that inventory is as per actual CW. The system is showing actual CW for the batch GR.
- Catch Weight Management – IS-CWM Functionality
IS-CWM is the industrial solution developed by SAP AG The term “Catch Weight materials” or CW materials for short, is used for materials with variable weight.
Catchweight management business scenario has variants across processes such as
(a) Procure to Pay
(b) Order to Cash
(d) Inbound and Outbound Logistic
(e) Inventory Controlling & Accounting
- IS-CWM enables the use of one UOM in Logistics and another UOM suitable for Financials and Controlling for the same material.
- Relationships between the two UOM’s can be variable and defined in the material master.
- Goods movement can be recorded in both UOM’s – base unit of measurement as well as a parallel unit of measure.
- The valuation UOM can be either the Base UOM or the parallel UOM – this can be specified in the material master.
- CWM is based on a new architecture comprising of
- a) LIME – Lean Inventory Management Engine – Enables recording and reporting of Inventory in different UOM.
- b) Inventory Accounting – Enables postings with new valuation UOM in FI and CO.
The fulfilment of purchase orders can be recorded and controlled more accurate for catch-weight materials. While posting goods receipt it is possible to post quantity in two different units of measure.
For an inventory, the logistics unit of measure (UOM e.g. EA ) and parallel unit of measure (e.g. KG)
Good Receipt MIGO
The same way it can be used for production/process order good receipts, posting of goods receipt is possible to post quantity in two different units of measure EA and KG.
You can view the stock in both the unit of measurement i.e; in the Base unit of measure and the Parallel unit of measure.
Material consumption in PI Sheet with CWM
The goods issues and goods receipts related to process or production orders can be recorded and controlled more accurate for catch-weight materials. All movements are posted in two units of measure (UOM) & parallel unit of measure
In the sales order, the price is calculated based on sold number of Kilo, number of Each is charged. The actual weight is assumed to be entered into the “Net weight” field in the delivery document.
